FramePro601, CH framing nailer

Article number 1G2101N

Description

This pneumatic framing nailer provides all the important features you want at an affordable price. A powerful Pro Serie framer that drives a wide range of clipped head fasteners in three diameters (2,9-3,1-3,3mm) from 50 to 90mm to handle virually any job. Its compact design makes the framer both easy to handle and easy on the arm. Whilst the 34° short, in-line magazines provide excellent maneuverability and line of sight.

Features & Benefits

  • Aggressive toenail safety
  • Dry fire lockout
  • 360° Adjustable Exhaust
  • Rafter hook
  • Selectable Trigger
  • Comfort grip
  • Tool-free depth-of-drive

Applications

Framing, Planks, Composite timbers, Wood construction, Subfloor, Fencing, Roofing

Specifications

Identificaton

Serie
Pro
Article number
1G2101N
GTIN
741474124631
Type
FramePro601

Technical specifications

Collation angle
34 °
Oil free
No
Operating temperature
-18 - 49 °C
Collation type
Paper collated
Firing mode
Dual
Magazine capacity
70
Air inlet size
3/8" female
Air consumption at 60 shots/minute
283.2 l/m
Operating pressure
4.8 - 8.3 bar
Sound pressure level
96.0 Lpa
Sound power level
101.0 Lwa
Vibration level
3.7 m/s2

Fastener specifications

Type of nail
CH stripnails
Smooth shank type
Smooth shank
Smooth shank nail length
50 - 90 mm
Smooth shank nail diameter
2,87 - 3,3 mm
Ring shank type
Ring shank
Ring shank nail length
50 - 75 mm
Ring shank nail diameter
2,87 - 2,87 mm
Screw shank type
Screw shank
Screw shank nail length
50 - 75 mm
Screw shank nail diameter
2,87 - 3,1 mm

Non-technical specifications

Warranty
1 year
Dimensions (DxWxH)
106 x 384 x 337 mm
Includes case
Yes

Logistical specifications

Net weight
3.62 kg
